Basic
Sensor: IMX432
Image Sensor: 1.1"CMOS
Shutter: Global
Resolution: 1604 × 1100
Frame Rate: 66 fps
Bit Depth: 12
Mono/Color: Color
Pixel Size: 9.0 μm × 9.0 μm
Pixel: 1.76 MP
S/N Ratio: ＞38dB
WDR: ＞70dB
Image Format: Mono8,BayerRG8/10/10Packed,BayerGB8/10/10Packed，YUV422Packed；
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 1μs~1 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 256 MB
Port
Port: GigE, PoE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output,
Lens Mount: C-mount
Power
Power Supply: PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈3.2W
Structure
Product Dimensions: 29 mm × 44 mm × 58 mm (not including lens mount and rear case connector)
Net Weight: 100 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
