Measuring range(XYZ): 800×1000×200mm
Glass stage size: 1208-885mm
Resolution of X/Y/Z axis: 0.5µm
Accuracy of X/Y axis: (3.5L/200)µm (l is measuring length in mm)
Repeatability of X/Y axis: 2µm
Objective: 0.7-4.5X
Working distance: 92mm
View field/diagonal length: 1.7-11.1mm
Magnification:20X-128X (on 19.5" monitor)
Camera: 1/2" color CCD, 0.3M pixel
Illumination
surface: coaxial Light programmable segmented ring fight
contour: adjustable LED light
Max. height of workpiece: 200mm
Max, weight of workpiece: 30kg
Operation ayam: Windows 7/8/10
Drive method:Automatic
Guide rail:Inear rail
Power supply: 100-240V 50/60
Operation environment: temperature: 20±2 °C temperature variation <1°C/h -2°C/24h <1 C/m; humidity 55%-65%
Dimension (LxWxH): 2170x2380x1560mm
Weight: 3260kg
