Maximum test force: 10kN
Accuracy class: 0.5 class
Accuracy of test force: ±0.5% of indicated value
Range of test force: 0.2%-100%FS
Test force resolution: 0.02N
Crossbeam displacement accuracy: ±0.1% of indicated value
Crossbeam displacement resolution: 0.1µm
Velocity accuracy: ±0.1% of indicated values
Range of speed adjustment: 0.001-1000mm/min
Effective test width: 420mm
Vertical test space
Standard model: 1200mm
Heighten 250mm: 1450mm
Heighten 500mm: 1700mm
Dimension (WxDxH)
Standard model: 748x582x1600mm
Heighten 250mm: 748x582x1850mm
Heighten 500mm: 748x582x2100mm
Weight
Standard model: 160 kg
Heighten 250mm: 185 kg
Heighten 500 mm: 210 kg
Power supply: AC220V, 50Hz, 1kW
Environment requirements: temperature: 5-40°C; humidity level: 5-85%RH, non-condensing, no vibration
