Max. test force: 600kN
Accuracy class: 0.5 class
Test force measurement accuracy: ±0.5% of indicated value
Range of test force: 0.2% - 100%FS
Resolution of test force: 1/500000FS
Crossbeam displacement accuracy: ±0.5% of indicated value
Crossbeam displacement resolution: 0.025μm
Range of speed adjustment: 0.001-250mm/min
Accuracy of crossbeam speed:
±1% of the set value, (speed<0.5mm/min)
±0.2% of the set value, (speed≥0.5mm/min)
Range of force control speed: 0.005~5%FS/S
Accuracy of constant load force:
±2% of the set value, (speed<0.05%FS/s)
±0.5% of the set value, (speed≥0.05%FS/s)
Compression fixture: Ø200mm
Wedge tension fixture
flat jaw: 0~30mm
V-jaw: Ø8-Ø46mm
Effective test width: 700mm
Vertical test space: 1100mm
Effective compression height: 650mm
Power supply: AC 380V, 50Hz, 2kW-5kW, 3Ø
Dimension: 1140x1580x2980mm
Weight: 5000kg
