Measuring range: thread: M1~M30
Reprocessing range: thread: M1~M20
Torque range: guide torque: 0~1.27N.m, max. torque: 0~1.27N.m
Speed range: 0~3000 r/min
Time range: retract time: 0.1~99s, interval: 0.1~99s
Power supply: 220V, 50/60Hz
Rated power:400W
Weight: 13kg
Dimension: 460×290x330mm
■ For inspection of GO, NO-GO and depth of threads
■ Can be for repair of thread defects
■ Real-time display of torque, circles, OK and NG counts
■ If NG thread is detected, audible and visual alarm are activated and the motor is automatically reversed to exit the thread gage Different thread gages and workpiece fixtures can be replaced
■ For different length of thread by adjusting the induction switch Thread gages with DLC coating, excellent wear resistance
■ Optional accessory: thread plug gages, thread ring gages, thread gage fixtures, custom-made workpiece fixtures, foot switch(code TCM-T20-01)
