Parameters: Ra, Rz, Rq, Rv, Rp, Rs, R3z, R3y, Rt, RC, Rz (JIS), Rk, Rku, Rsm, Rpc, Rpk, Rvk, Rsk, Mr1, Mr2, Ry, Rmax
Range:
X axis: 17.5mm
Z axis: 640μm (-320μm~320μm)
Accuracy: ±10%
Resolution (Ra): 0.001μm
Probe
type: inductive
stylus radius/angle: 5µm/90°
stylus material: diamond
Measuring force: 4mN
Measuring unit: μm/pin
Cut off: 0.25/0.8/2.5mm
Number of cut-offs: 1-5
Traverse speed: 0.135mm/s, 0.5mm/s, 1mm/s
Memory: 100 measurement results
Output: bluetooth and USB
Power: built-in rechargeable battery
Dimension (LxWxH): 158×64×52mm
Weight: 400g
