Automatic probe leveling
Language: English, French, German, Italian, Spanish, Portuguese
12 roughness parametrers
Can set tolerence
Measuring range up to 100um, can measure grit and shot blasting.
Traverse length up to 16mm
The probe can rotate from 90 °or 270 ° for transerve measurement
Memory of maximum 100 results
Remark: probe can't be changed
Parameters: Ra, Rq, Rt, Rz, Rmax, Rsm, Rpc, Rmr, R, AR, Rx
Range: Ra: 0-100um, Rt: 0.05-400um
Accuracy: +-3%
Resolution (Ra): 0.001um
Probe type: inductive
Probe Stylus radius/ angle: 5um/90 °
Probe stylus material: diamond
Measuring force: 0.75mN
Measuring unit: um/uin
Cut off: 0.25/0.8/2.5mm
Numbers of cut-offs: 1-5
Traverse speed: 1mm/s
Memory: 100 measurement results
Output: USB
Power: built-in rechargeable results
Dimension: 122x52x68m
Weight: 650g
