Power supply: 110V,50/60Hz
Lens:
Magnification: 10X
View field: Ø40mm
Worrking distance: 103.9mm
Magnification accuracy: +/-0.08%
Projector screen:
Diameter: Ø400mm
Rotation range: 0°~360°,resolution:1" or 0.01°
Reference line: Cross-hairs
Stage:
Metal stage size: 450x200mm
Turning range: +/-15°
X-Z stage travel:range:250x150mm, resolution: 0.5µm, accuracy: (4+L/25)µm;L(mm)
Y (focus) travel range: 100mm
Max. load capacity: 50Kg
Output: RS232C
Demension(LxWxH): 1215x646x1210mm
Weight: 240kg
Standard delivery: Main unit,Switch foot, Anti-dust cover, Overlay chart clip(4pc).
