Accuracy class: ±2%FS
Range of test force: 2.0~200.0cN
Test force resolution: 0.1cN
Width of measuring: 65mm
Factory calibrated wire diameter: Ф0.2mm
Range of diameter: 0.05~0.3mm
Compensation for diameter: Yes
Frequency of display updates: 2 times/sec
Maximum line speed: 2000 m/min
Power supply: built-in rechargeable battery
Environmental requirements: temp: 10~45°C, humidity: 90% RH
Standard Deliery:
Main unit: 1pc
■ Suitable for testing the tension of stranding machines, winding machines, wire cutting machines, carbon fibre winding equipment, fibre optic winding equipment, fibre optic cable production equipment, glass fibre winding equipment, steel cord production equipment, steel wire rope production equipment and so on.
■ Automatic zeroing, manual zeroing also possible
■ Memory function for recording the current real-time value (up to 10 data), for recording phase data (max., min., average).
■ 10 calibration channels, 6 groups of calibration points to choose from
■ Fine-tunable compensation, compensation value range ±10%FS, 1% for one component
■ Six units g, cN, N, Ib, daN, kg are automatically converted.
■ 3 min no operation auto shutdown
