Range: 8HV - 2900HV
Stage lifting: manual
Load control: automatic(load/dwell/yoload)
Load dwell time: 1-99 second
Objective: 10X,40X
Eyepiece: 10X
Total magnification: 100X (for measurement of observation), 400X (for measurement)
Data output: built-in printer
Max.workpiece height: 160mm
Max. Testing width: 160mm (from the center of indenter to the wall of main body)
X-Y stage:
Dimensions: 150x150mm, travel range:50x50mm, graduation:1um,
Displacement repetition accuracy: les than 3um
Pixel:5M
Power supply:220V 50/60Hz
Demension:62x250x710mm
Weight: 50kg
