Specification
Withstand voltage test:
Output voltage:
Range: AC: 5kV; DC: 6kV
Resolution (d): 0.001kV
Accuracy: ±(2%+5d)
Test current:
Range: AC: 10mA; DC: 5mA
Resolution (d): AC: 0.001mA~0.01mA; DC: 0.1µA-0.01mA
Accuracy: ±(2%+5d)
Insulation resistance test:
Output voltage:
Range: 1kV
Resolution (d): 0.001kV
Accuracy: ±(1%+2d)
Test resistance:
Range: 10GΩ
Resolution (d): 0.001ΜΩ~0.01GΩ
Accuracy:
output voltage≥500V, test resistance 1ΜΩ-1GΩ: ±(5%+5d)
output voltage≥500V, test resistance 1GΩ-10GΩ: ±(10%+5d)
output voltage<500V, test resistance 0.1ΜΩ-1GΩ: ±(10%+50)
Discharge function: discharge after testing
Arc detection: 1-9 level (AC/DC), factory default is 5
Time:
voltage rising time: 0.1s~999.9s;
voltage falling time: 0.1s~999.9s;
voltage testing time: 0.1s-999.9s
Interface: HANDLER interface, RS232C interface, USB interface
Operation environment: temperature: 10°C~40°C; relative humidity: ≤70%
Power supply: AC 110V/220V, 50Hz/60Hz
Dimension (LxWxH): 450x270x130mm
Weight: 9.2kg
Standard Delivery:
Main unit: 1pc
High voltage test clip: 2pcs
High voltage test rod: 1pc
RS232 communication cable: 1pc
■ 5-inch LCD touch screen display
■ Arc detection function
■ Electric shock protection function
■ 10 test files can be stored, each file can be edited with
16 test steps.
■ Standard communication interface to meet automation test requirements.
■ Applications: home appliance, transformer, electrical device, component.
