Illumination: 12V/30W (transmitted); 12V/50W (reflected)
Objective (infinite plan achromatic): bright & dark field objectives: 5X; 10X; 20X; 40X
Working distance: 9.70mm; 9.30mm; 7.20mm; 3.00mm
Numerical aperture: 0.12; 0.25; 0.60; 0.70
Magnification: 50X~400X
Eyepiece (wide field): 10X (view field: ϕ22mm)
Stage:
- Double layer
- Size: 210x140mm
- Travel: 75x50mm
Pupil distance: 53~75mm
Diopter adjustment: ±5 diopter (one eyepiece)
Power supply: 220V, 50/60Hz
Dimension: 456x260x498mm
Weight: 11kg
Standard delivery:
- Main unit: 1pc
- Anti- dust cover: 1pc
- Filter (blue/frosted glass): 1pc
Optional accessory:
- Bright and dark field objectives
- 10X dividing eyepiece (0.1mm/div.)
