Sampling Flow:
Range: 2.83L/min (0.1ft³)
Accuracy: ±5%
Particle:
Particle Diameter Passage: 0.3µm, 0.5µm, 1µm, 3µm, 5µm, 10µm, simultaneous counting of six particle diameters
Repeatability: ≤10%FS
Error of Particle Sizes: ±30% (0.5µm, 5µm)
Accuracy: ±30%FS (0.5µm)
Self-cleaning Time: ≤10min
Delay Sampling Time: 0~99s
Sampling Time: 1s~9999s
Sampling Mode: single, repeated, continuous, calculate, remote
Unit Conversion: m³, ft³
Counting Mode: cumulative value, difference value, concentration value
*UCL Setting:
Sampling Points (A): set from 2 to 9
Sampling Times per Point (L): set from 2 to 9
Location: set from 0 to 999
Alarm Setting: the instrument is equipped with a cleanroom level alarm function, which will alarm when it exceeds the standard of class 100, 1000, 10000, 100000, 300000, 1000000, and will also alarm when the battery voltage is too low
Data Storage: store 1000 sets of data (including particle size, data, environmental data, time, sample volume, data location), no data loss after power failure
Environmental Requirement: temperature: 0~40°C, relative humidity: 20~90%, no condensation, the instrument should be used in a non-corrosive air environment
Power Supply: 16.8V rechargeable Li-ion battery, working time 8h
Dimension: 230×130×450mm
Weight: 600g
*Upper confidence limit of 95%
STANDARD DELIVERY:
Main Unit: 1pc
Isokinetic Sampling Port: 1pc
High Efficiency Filter: 1pc
Communication Cable: 1set
Adapter: 1pc
USB Disk: 1pc
