Thermocouple type: J/K/T/E/R/S/N
Temperature range (electrical signal):
K: -200°C~1372°C
J: -210°C~1200°C
T: -250°C~400°C
E: -150°C~1000°C
R: 0°C~1767°C
S: 0°C-1767°C
N: -200°C~1300°C"
Temperature accuracy* (electrical signal):
±(0.2% |t| +0.5°C) (at -10°C-1767°C);
±(0.2% |t| +1.0°C) (at -200°C~-10°C);
±(0.2% |t| +2.5°C) (at -250°C~-200°C)
Temperature resolution:
0.1°C (<1000°C); 1°C (≥1000°C)
Repeatability: ±(0.1% |t| +0.3°C)
Response time: 500ms
Logging interval: 1s~24h (adjustable)
Memory capacity 72000
Data transmission: USB TYPE-C, Bluetooth
Power frequency anti-interference: 50/60Hz
Input proof: 60Vmax
Drop proof: 1m
Power supply: 3×AAA alkaline batteries, working time>30h; TYPE-C USB (only be connected to a PC power)
Operation environment:
Temperature: -10°C~50°C
Humidity: <90%RH (non-condensing)
Storage environment:
Temperature: -20°C~60°C
Humidity: <90%RH (non-condensing)
Dimension: 180mm x 63mm x 38mm
Weight: 250g (including batteríe)
*Accuracy is specified for ambient temperature between 18°C and 28°C, the above specification does not include thermocouple probe error
Standard delivery
Main unit: 1pc
Battery (AAA): 3pcs
USB cable: 1pc
K-type thermocouple (0323-K01): 4pcs
Specification of K-type Thermocouple*:
Code: 0323-K01
Range: -40°C~260°C
Accuracy: ±0.75%
Length: 900mm
*Other models, temperature range and length of thermocouples can be customized
■ Unit °C/°F/K
■ Channels are compatible with 7 types of thermocouples K, J, T, E, R, S and N MAX/MIN/AVG/DIF mode
■ 72000 data storage
■ Offset value compensation Data hold function
■ Display backlight Over range indicator
■ Battery level display
■ Automatic power off
■ Built-in Bluetooth, mobile APP is included
■ Computer software is included
Datasheet
