Core: ARM Cortex M4
Range: 100 m
Width: 8 mm
Height: 1 mm
Length: 8 mm
Antenna: Integrated
Protocol: BLE, Bluetooth 5.0
Data Rate: 2 Mb/s
Frequency: 2.44 GHz
Dimensions: 8 mm x 8 mm x 1 mm
Memory Size: 64 kB, 512 kB
Sensitivity: - 96 dBm
Unit Weight: 260 g
Output Power: 4 dBm
Interface Type: I2C, PDM, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Moisture Sensitive: Yes
Protocol - Sub GHz: NFC
Receiver Sensitivity: - 96 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.7 V
Antenna Connector Type: Integrated
Operating Supply Voltage: 1.7 V to 3.6 V
Supply Current Receiving: 6.5 mA
Supply Current Transmitting: 7.1 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
