Fall Time: 15 ns
Rise Time: 16 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N Channel
Qg - Gate Charge: 90 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 217 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 17 ns
Typical Turn-Off Delay Time: 31 ns
Id - Continuous Drain Current: 275 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 28 S
Rds On - Drain-Source Resistance: 1.55 mOhms
Vds - Drain-Source Breakdown Voltage: 60 V
Vgs th - Gate-Source Threshold Voltage: 3.45 V
