Width: 3 mm
Height: 1 mm
Length: 3 mm
Fall Time: 60 ns
Rise Time: 27 ns
Technology: Si
Unit Weight: 122.136 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 16 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 2.8 W
Vgs - Gate-Source Voltage: - 25 V, + 25 V
Typical Turn-On Delay Time: 11 ns
Typical Turn-Off Delay Time: 72 ns
Id - Continuous Drain Current: 11 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 16 S
Rds On - Drain-Source Resistance: 11.7 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.8 V
