Width: 3.3 mm
Height: 0.9 mm
Length: 3.3 mm
Fall Time: 5.1 ns
Rise Time: 5.8 ns
Technology: Si
Unit Weight: 122.136 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 17 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.8 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 5 ns
Typical Turn-Off Delay Time: 16 ns
Id - Continuous Drain Current: 3.2 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 20 S
Rds On - Drain-Source Resistance: 92 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 1.8 V
