Width: 3.3 mm
Height: 1 mm
Length: 3.3 mm
Fall Time: 2 ns
Rise Time: 2 ns
Technology: Si
Unit Weight: 38.760 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 13.7 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 34 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 3 ns
Typical Turn-Off Delay Time: 3 ns
Id - Continuous Drain Current: 40 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 7 mOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2.2 V
