Fall Time: 3.8 ns
Rise Time: 12 ns
Technology: Si
Unit Weight: 187.650 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 42 nC
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 124 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 25 ns
Typical Turn-Off Delay Time: 85 ns
Id - Continuous Drain Current: 22 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
Rds On - Drain-Source Resistance: 115 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 3.5 V
