Fall Time: 11 ns
Rise Time: 1.1 ns
Technology: SiC
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 9.4 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 83 W
Vgs - Gate-Source Voltage: - 7 V, + 20 V
Typical Turn-On Delay Time: 6.5 ns
Typical Turn-Off Delay Time: 16 ns
Id - Continuous Drain Current: 13 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 1.9 S
Rds On - Drain-Source Resistance: 294 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 5.1 V
