Fall Time: 3 ns
Rise Time: 4 ns
Technology: Si
Unit Weight: 38.760 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 37 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 69 W
Vgs - Gate-Source Voltage: - 16 V, + 16 V
Typical Turn-On Delay Time: 5 ns
Typical Turn-Off Delay Time: 26 ns
Id - Continuous Drain Current: 40 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 80 S
Rds On - Drain-Source Resistance: 1.1 mOhms
Vds - Drain-Source Breakdown Voltage: 25 V
Vgs th - Gate-Source Threshold Voltage: 2 V
