Width: 61.4 mm
Height: 36.5 mm
Length: 106.4 mm
Technology: Si
Unit Weight: 340 g
Configuration: Single
Mounting Style: Screw Mount
Pd - Power Dissipation: 2.8 kW
Gate-Emitter Leakage Current: 400 nA
Maximum Gate Emitter Voltage: 20 V
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
Collector- Emitter Voltage VCEO Max: 1.2 kV
Collector-Emitter Saturation Voltage: 1.7 V
Continuous Collector Current at 25 C: 900 A
