Stirring quantity max. per stirring position (H2O): 5 l
Motor rating input: 32 W
Motor rating output: 22 W
Motor principle: Brushless DC
Speed display: LED
Speed min.: 50 rpm
Speed min.: 0/50 rpm
Speed max.: 2000 rpm
Viscosity max.: 4000 mPas
Output max. at stirring shaft: 15.7 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 7.5 Ncm
Torque max. at stirring shaft at 60 1/min (overload): 7.5 Ncm
Torque max. at stirring shaft at 100 1/min: 7.5 Ncm
Torque max. at stirring shaft at 1.000 1/min: 7.5 Ncm
torque I max.: 7.5 Ncm
Speed range I (50 Hz): 50 - 2000 rpm
Speed range I (60 Hz): 50 - 2000 rpm
Speed control: Turning knob
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement n > 300rpm: 1 ±%
Deviation of speed measurement n < 300rpm: 3 ±rpm
Stirring element fastening: chuck
Plug-in coupling (Ø): 5.5 mm
Chuck range diameter: 0.5 - 8 mm
Hollow shaft, inner diameter: 8.5 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 13 mm
Extension arm length: 160 mm
Nominal torque: 0.075 Nm
Timer display: none
housing material: alu-cast coating / thermoplastic polymer
Dimensions (W x H x D): 60 x 173 x 126 mm
Weight: 1.18 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 54
USB interface: yes
Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power input: 32 W
Power input standby: 0.3 W
DC Voltage: 24 V=
Current consumption: 1300 mA
