Viscosity Measuring Range: 320000000 mPas
Viscosity Accuracy (FSR): 1 %
Viscosity Repeatibility (FSR): 0.2 %
Spring torque: 5.7496 mNm
Guard rail: me-vi
Measuring spindle series: SP set-2
Motor rating output: 4.8 W
Overload protection: yes
Direction of rotation: right
Display: TFT
Speed display: TFT
Speed range: 0.01 - 200 rpm
Setting accuracy speed: 0.01 ±rpm
Speed control: TFT
Torque display: yes
Torque measurement: yes
Timer: yes
Timer display: TFT
Time setting range: 0.017 - 6000 min
Temperature measurement resolution: 0.1 K
Working temperature display: TFT
Connection for ext. temperature sensor: PT 100
Graph function: yes
Operating mode: timer and continuous operation
Calibration option: yes
Touch function: yes
Pemitted density: 9999 kg/dm3
Working temperature: -100 - 300 °C
Fastening on stand: extension arm
Support rod diameter (with integrated fastening on stand): 16 mm
Telescope stand stroke: 200 mm
Plug-in coupling (Ø): 12 mm
Basic container volume: 600 ml
Stand: Rotastand
Stroke max.: 200 mm
Diameter: 16 mm
Dynamic load: 5 kg
Dimensions (W x H x D): 351 x 629 x 372 mm
Weight: 7.1 kg
Permissible ambient temperature: 0 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 40
RS 232 interface: yes
USB interface: yes
Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power input: 24 W
Power input standby: 0.06 W
DC Voltage: 24 V=
Current consumption: 1000 mA
