Width: 12.7 mm
Height: 15.7 mm
Length: 29 mm
Coil Type: Non-Latching
IP Rating: IP20
Coil Current: 32 mA
Coil Voltage: 12 VDC
Contact Rating: 6 A
Mounting Style: Panel Mount
Coil Resistance: 375 Ohms
Contact Material: Silver Nickel (AgNi)
Power Consumption: 380 mW
Switching Voltage: 250 VAC
Relay Contact Form: 2 Form C (DPDT-NO, NC)
Contact Termination: Solder Pin
Contact Current Rating: 6 A
Maximum Switching Current: 6 A
