Power Supply:
AC: AC220V±10%,50Hz±1Hz
DC: Built-in 14.8V/2.6AH Lithium battery
Output current: 20mA, 200mA, 2A(automatic selection based on range)
Output voltage of open circuit: DC12V
Range (Automatic switch of resistance range):
2A (Max.5.5Ω): 0.0001mΩ-4.9999mΩ; 0.001mΩ-49.999mΩ; 0.01mΩ-499.99mΩ; 0.0001Ω-4.9999Ω;
200mA (Max.55Ω): 0.01mΩ-499.99mΩ; 0.0001Ω-4.9999Ω; 0.001Ω-49.999Ω;
20mA (Max. 22kΩ): 0.0001Ω-4.9999Ω; 0.001Ω-49.999Ω; 0.01Ω-499.99Ω; 500.00Ω-999.99Ω; 1.000kΩ-9.999kΩ; 10.00kΩ-19.99kΩ;
Accuracy:
- Less than 1.000kΩ: ±(0.2%RD+0.05%FS)
- 1.000kΩ and above: ±(0.2%RD+0.1%FS)
Min. Resolution: 0.1μΩ
Storage: 10000groups
Display: LCD display
Working environment: -10～40℃
Environmental humidity: ≤80%RH, no condensation
Storage condition: -20℃~50℃, ≤95%RH, no condensation
Size: 170mm×119mm×45mm
Weight: 595g(with battery)
