Input: AC380V ± 10%
Frequency: 50Hz ± 1
Output: 0-200kV, AC RMS
Rating: 100% Rated-1minute, 50%-continuous
Capacity: 20kVA (based on selectable)
HV Source: SF6 gas
Output control: Manual control
Voltage accuracy: ≤ 2.0% (F.S)
Current Accuracy: ≤ 2.0% (F.S)
Timing range: 0-99H
Metering Digital display, kV meter: 0-200kV,
mA meter: AC 0-100mA
Humidity: 85% RH
Environmental temperature: -20℃~50℃
Weight Control Unit: About 90kg
Gas Testing transformer: About 120kg
Accessories:
1x Control Unit
1x Gas testing transformer (HV unit)
1x Power cord
1x Metering cable
1x Output cable
1x HV cable
1x Ground cable
1x User's guide
1x Factory test report
