Input: AC 220V± 10%, 50Hz, 32.5A, Single phase
Output:
0-130kV, 50mA
0-36kV, 180mA
Rating:
25mA/90mA, continuous working
33.3kV/120mA, 1hour ON/1hour OFF
50mA/180mA, 5mins ON/15mins OFF
Capacity: 6.5kVA
HT Source: SF6 gas (Gas testing transformer)
Output control: Manual control
Voltage accuracy: ≤ 1.5% (F.S)
Current Accuracy: ≤ 1.5% (F.S)
Timing range: 0-99H
Metering:
LCD display
kV meter: there is a switching button, the range is 0-36kVAC if it switches to 36kV, the range is 0-130kVAC if it switches to 130kV
mA meter: 0-5.000mA
Humidity: 85% RH
Environmental temperature: -20℃～50℃
