HV HIPOT GD2672B Insulation Resistance Tester (DC 30~600V; AC 30~600V)

Measurement range: DC 30~600V; AC 30~600V(50/60Hz)

Resolution: 1V

Accuracy: 2%rdg ±3dgt

Display: LCD display up to 999 counts (1000 counts are displayed at 1T) Bar graph / max 36 points

Overrun indication:

- OL: mark appears on the insulation resistance range

- LO: The mark appears on the voltage range

Auto range:

- Higher range: 1000 counts

- Lower range: 95 counts (only on the insulation resistance range)

Sampling rate: 0.5~10times/s

Altitude: ≤2000m (indoor use)

Operating condition: Temperature:0℃~40℃/ humidity: ≤85%

Storage condition: Temperature:-20℃~60℃/ humidity: ≤90%

Overload protection: Insulation resist range：AAC 1200V/10 s

Voltage range: AC 720V/10 s

Withstand voltage: AC 8320V (50/60HZ)/5s(between circuit and shell)

Insulation resistance: ≥1000MΩ/DC 1000v(between circuit and shell)

Power supply: DC12V (8*1.5V LR14battery)

Current consumption: About 800mA (max.) (usually keep at 20mA)

Battery lifetime: About 15hours

Dimension: 153*213*95mm

Weight: 1027g( without battery and test wire)
