Drive mode: Servo motor;
Control method: PLC touch screen control;
Force range: 1～20kN;
Extrusion stroke: 250mm;
Force value display: PLC touch screen control;
Extrusion head area: ≥20cm²;
Extrusion degree: Extrusion pressure reaches 13±0.2kN, keep it for 1min;
Test space: 200x200x200mm (width x depth x height);
External material: A3 steel plate and painted, thickness 1.5mm
Material of inner box: SUS#304 thickness 1.2mm;
Inner box size: 520x450x560mm
Dimensions: 800x700x1720mm
Weight: about 220kg
Power supply: AC380V, 50HZ
