Gain: 5 dBi, 5 dBi, 6 dBi, 6 dBi, 8.5 dBi, 7 dBi, 7.5 dBi
VSWR: 2, 1.5, 2.2, 1.5, 1.5, 1.7, 1.5
Style: Sharkfin
Width: 100 mm
Height: 90 mm
Length: 256 mm
IP Rating: IP68
Impedance: 50 Ohms
Application: Rail, Railway Rooftop
Unit Weight: 1.065 kg
Polarization: Vertical
Power Rating: 100 W
REACH - SVHC: Details
Mounting Style: Screw Mount
Number of Bands: 7 Band
Center Frequency: 742 MHz, 1610 MHz, 1350 MHz, 2205 MHz, 3000 MHz, 4100 MHz, 5662.5 MHz
Mechanical Style: Module
Maximum Frequency: 6.425 GHz
Minimum Frequency: 694 MHz
Termination Style: Connector
Antenna Connector Type: N Female
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 45 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE)
