Power supply
Power dissipation: <2000VA
Ac power supply: 220V±20%(47～63Hz)
Dc power supply: 200～380 VDC
AC voltage source output
Measuring range: 6×125 V,125V/60VA per channel
Accuracy: 0.2~2V,±2mV;2V~130V,±0.05%
Resolution: 1mV
AC voltage source output
Measuring range: 6×30A,30A/300VA per channel
Accuracy: 0~500mA,±1mA; 500mA~30A,±0.05%
Resolution: 1mA
Output phase
Range: 0~360°
Accuracy: <±0.001Hz(0~65Hz) <±0.02Hz(450~1200Hz)
Resolution: 0.001 Hz
DC voltage source output
Range: -175～+175V(L-N),1*0～350V(L-L)
Accuracy: 0.1%
DC voltage source output
Range: 6 channels, each 0~30A/250VA
Accuracy: 0.1%
Independent auxiliary DC
110/220VDC is switchable, power no less than 100W
Precision: 0.5%
Synchronous interface
Number: GPS/BD ANT 1 piece;IRIG-B/PPS optical signal 2 pieces: 1 time synchronization and 1 time service; IRIG-B/PPS signal 2 pairs：1 pair time synchronization and 1 pair time service; IEEE 1588 1 pair
Interface type: GPS/BD ANT, IRIG-B/PPS optical signal; IRIG-B/PPS electric signal; IEEE 1588
Time measurement
Range: 1ms~9999.999s
Accuracy: 1ms
Digital Input: Number: 8 pairs
Digital Output
Number: 6 pairs,among them, 2 pairs are fast opening (reaction time ≤0.1ms), which can be added
Interrupting capacity: DC250V /0.5A
Wireless connections: Interface type: WIFI,4G
Wired connection (Ethernet communication interface): Number of ports: 2
Interface type: 100 megabit LAN port, RJ45
Power supply
Supply voltage: AC/DC 220V, Tolerance error：±20%
Power supply frequency: 47~65 Hz
Auxiliary power supply: 110V/220V each channel
Analog small signal input (optional)
Number of channels: 12
Interface type: Aviation plug, AC voltage
Analog small signal output (optional)
Number of channels: 12
Interface type: Aviation plug, AC voltage
USB Interface: Number:3
Working environment conditions
Operating temperature: -10℃~50℃
Humidity: ≤95%, No condensation
Others: On-line interface: RJ45
