Input voltage： AC220V ±10%
Power：5KVA
Output voltage：
series：AC0～500A（10V）
parallel：AC0～1000A（5V）
Stepless adjustable, panel with digital display ammeter
Output voltage： >10V
Output waveform: the output current is the standard sinusoidal wave with small burrs, which is better than the standard power system requirements.
Measuring accuracy :(using grade 0.2S material) the actual value is around 0.3; Each current can be smoothly, smoothly and continuously adjustable, and the precision is higher than 0.5 level. The current voltmeter shows true and effective value with high accuracy and stability.
Output current mode: true RMS value is continuously adjustable;
Current stability: 0.2%
Structure and form: integrated
Wiring mode: according to requirements
Current stability: 0.2%;
Protection Settings: over-current and over-voltage
0.001S-99999.999S
