Parameter: Leakage current and insulation resistance
Output Voltage: 1V~1000VDC
Accuracy: <10G:3%, ≥10G: 5%, ≥100G:10%
Measurement Range:
100kΩ~10TΩ
10V: 100kΩ~100GΩ;100V: 1MΩ~1TΩ;1000V: 10MΩ~10TΩ
Max Reading: 9999
Range: Automatic and Manual
Speed: 55 times/second,15 times/second,3 times/second
Adjustment: Open-circuit Zero-Adjust for each range
Result Display: Show, current, resistance, peak value, and sorting result
Charging Timer: 999.9s
Comparator: 30 sets record,GD/NG Beep: GD,NG,OFF setting.
Interface:
RS-232C interface Handler interface
(AT682SE optional interface)
Others: VFD four color high-definition screen,keypad lock and data hold function
GENERAL FEATURES
Power Supply: Voltage: 198VAC~240VAC Frequency: 50Hz Power: Max 30VA
Dimension: 264(W)mm x 107(H)mm x 350mm(D)
Weight: 5kg
