Number of channels: 1 channel
Range of pulse voltage: 1KV-10KV
Accuracy of pulse voltage: ±5%±50V
Step of pulse voltage: 200V
Measurement speed: Approx. 5 times/s
High-voltage power supply control: Switching power supply is controlled by MCU
Numbers of impulses: Single EXT (1-29 times); continuous INT
Trigger mode: Manual, Foot control, PC
Detection and judgment mode: Area; differential area; corona discharge quantity; phase
Sound mode: "Up to standard" sound; "Not up to standard" sound; mute
Storage capacity of waveform: 100 waveforms and their parameters
Waveform resolution: A/D： 8 bit; sampling speed： 25nS (40MHz); point number of waveform： 250
LCD: Resolution: 320 x 240; 5.1 inches; white letters on a blue background
Dimension: 400(W)×132(H)×430(D)
Weight: Approx. 10Kg
Environment condition:
Operating temperature:10℃-30℃; Operating humidity: 20%-80% RH
Storage temperature: 5℃-40℃; storage humidity: 5%-90%RH
Special functions and parameters: Customized according to user requirements
