Power input: AC: 380V. 75A
Power supply: AC: 220V. 1A, 50Hz/60HZ
Output current: AC:5000A. 5V or 2500A. 10V
LCD display shows current value, ratio and phase angle at one time and two Times.
Primary current range: 0~5500A, resolution: 0.1A,
Two measuring current Range: 0~6A, resolution: 0.001A, accuracy: 0.5%
Accuracy: 0.5%
Use environment: temperature -10~40℃, relative humidity 80%
Host: 430mm × 430mm × 470mm;
External pressure regulator: 515mm × 375mm × 950mm;
Wire box: 385mm × 270mm × 380mm × 2 pieces.
Weight: Host 108Kg, external voltage regulator 120Kg, wire box (2) 55Kg.
