Detector type: UFPA
Spectral range: 8 ~ 14µm
Resolution / Pxl size: 160 x 120 pxl / 17µm
Thermal sensitivity/NETD: <0.05°C @ 30°C / 50mK
Field of View (FOV: 20.7° x 15.6°
Focal lens / F-number: 7.5mm / 1.0
Minimum focal distance: 0.5m
IFOV (@1m): 2.26mrad
Focusing: Manual on lens
Image frequency: 50Hz
Color palettes: 8 Standard + 4 Isotherms
Integrated camera: 2Mpxl, FOV 65°
Display type: 3.5” TFT color, capacitive touch-screen, high brightness
Image mode: IR, Visible, Fusion PiP, Auto Fusion
IR Video: Recording and saving MP4 format
Electronic zoom: x1 ÷ x32 in continuous way
Temperature measurement range: -20°C ~ 650.0°C / -4.0°F ~ 1202.0°F
Temperature measurement screening mode range: 32.0°C ~ 42.0°C / 89.6°F ~ 107.6°F
Encapsulation: IP54
Dimensions (L x W x H) 240 x 100 x 110mm
Weight (battery included) 480g
Memory Internal memory (3.4GB) + Micro SD card 16GB (max 32GB)
File format: JPEG standard (snapshots), HIR (radiometric)
PC: interface USB-C
Battery type: Rechargeable Li-ION, 3,7V 2600mAh
External power: External adapter 100/240VAC (50/60Hz)/5VDC, 2400mA
