DC VOLTAGE : 600.0mV/ 6.000V / 60.00V/ 600.0V/ 1000V ; (1.0%rdg+2dgt); 10M; 1000VDC/ACrms
AC TRMS VOLTAGE:
6.000V/ 600.0V/ 60.00V; ±(1.0%rdg+8dgt); ±(2.0%rdg+8dgt); 1000VDC/ACrms
1000V; ±(1.2%rdg+3dgt); ±(2.5%rdg+3dgt) ; 1000VDC/ACrms
DC CURRENT:
600.0µA/ 60.00mA/ 6000A/ 600.0mA ; ±(1.0%rdg+3dgt); Fast Fuse 0.8A/1kVAC/DC (inputs mA, µA)
6.000A; ±(1.5%rdg+3dgt); Fast Fuse 10A/1kVAC/DC (input 10A)
AC TRMS CURRENT:
600.0µA/ 6000µA/ 60.00mA/ 600.0mA; ±(1.5%rdg+3dgt)p Fast Fuse 0.8A/1kVAC/DC (inputs mA, µA)
6.000A; ±(2.0%rdg+3dgt) Fast Fuse 10A/1kVAC/DC (inputs 10A)
DIODE TEST : 0.9mA; 2.8V; 1000VDC/ACrms
RESISTANCE AND CONTINUITY TEST
600.0Ω/ 6.000kΩ/ 60.00kΩ/ 600.0kΩ/ 6.000MΩ ; ±(1.0%rdg+4dgt); 2.8V; <100; 1000VDC/ACrms
60.00MΩ; ±(2.0%rdg+10dgt); 2.8V; <100Ω; 1000VDC/ACrms
FREQUENCY (Electronic circuits):
9.999Hz/ 99.99Hz/ 999.9Hz/ 9.999kHz/ 99.99kHz/ 999.9kHz/ 9.999MHz;
±(0.1%rdg+2dgt);0.8Vrms min (20% < duty < 80%, <100kHz) 5Vrms min
(20% < duty < 80%, >100kHz) 1000VDC/ACrms
FREQUENCY (Electrical circuits):
10 ÷ 400Hz; ±(1.5%rdg+5dgt); 15Vrms\ 10Arms; 1000VDC/ACrms
DUTY CYCLE: 0.1 ÷ 99.9%; ±(1.2%rdg+2dgt); 1000VDC/ACrms
CAPACITANCE:
40.00nF; ±(3.5%rdg+50dgt); 1000VDC/ACrms
400.0nF/ 4.000µF/ 40.00µF/ 400.0µF; ±(3.5%rdg+4dgt); 1000VDC/ACrms
1000µF; ±(5.0%rdg+5dgt); 1000VDC/ACrms
TEMPERATURE WITH TYPE K PROBE:
-45°C ÷ 400°C/ 401°C ÷ 750°C;±(3.5%rdg+5°C); 1000VDC/ACrms
-50°F ÷ 752°F/ 752°F÷ 1382°F; ±(3.5%rdg+9°F); 1000VDC/ACrms
Display: LCD, 3½dgt, 6000 counts, sign, decimal point and bargraph; Automatic polarity indication; Backlight; “OL” over range indication; Response time: 2/s
Features: Data HOLD; MAX/MIN; RANGE; REL; Auto Power OFF after 15 minutes of idleness
Altitude max of use: 2000m
Pollution degree: 2
Insulation: double insulation
Power supply: 1x9V alkaline battery NEDA 1604 IEC 6F22
Dimensions (L x W x H): 175 x 85 x 55mm
Weight (included battery): 390g
Accessories:
K-TYPE WIRE PROBE TK101
Adapter T10
ISO9000 calibration certificate
Bag B80
Pair of Leads KIT4000A
Batteries and user manual
