DC current: 60.00mA/ 600.0mA/ 6.000A/ 10.00A; ±(0.8%rdg+3dgt); Fuse 440mA/1kVAC/DC,10kA (input mA)/ Fuse 11A/1kVAC/DC,20kA (input A)
AC TRMS current : 60.00mA/ 600.0mA/ 6.000A / 10.00A; ±(1.2%rdg+3dgt) Fuse 440mA/1kVAC/DC,10kA (input mA)/ Fuse 11A/1kVAC/DC,20kA (input A)
AC+DC TRMS current: 60.00mA/ 600.0mA/ 6.000A/ 10.00A; ±(2.0%rdg+5dgt); Fusibile 440mA/1kVAC/DC,10kA (ingresso mA)/ Fusibile 11A/1kVAC/DC,20kA (ingresso A)
Resistance:
600.0Ω; ±(0.8%rdg+5dgt) ; <2.5V; 1000VDC/ACrms
6.000kΩ(<2.5V)/ 60.00kΩ / 600.0kΩ/ 60.00kΩ/ 600.0kΩ / 6.000MΩ(<0.6V ); ±(0.8%rdg+2dgt); 1000VDC/ACrms
40.00MΩ; ±(1.0%rdg+5dgt); <0.6V; 1000VDC/ACrms
Continuity Test: 600.0Ω; ±(0.8%rdg+5dgt); 1000VDC/ACrms
Diode Test: 2.000V; 1mV ±(1.5%rdg+2dgt); <2.5V; 1000VDC/ACrms
Frequency: 100.00Hz/ 10.000kHz/ 100.00kHz; ±(0.1%rdg+2dgt); 1000VDC/ACrms 1000.0Hz 0.1Hz
Capacitance: 1.000µF/10.00µF/ 100.0µF/ 1.000mF (<0.7s), 10.00mF ( <3s ); ±(1.2%rdg+2dgt); 1000VDC/ACrms
Temperature with type K probe:
-40.0°C ÷ 400.0°C; ±(1.0%rdg+10dgt); 1000VDC/ACrms
-40.0°F ÷ 752°F; ±(1.0%rdg+18dgt); 1000VDC/ACrms
Display: LCD display, 4 digit with maximum reading 6000 counts with sign, decimal point and bargraph; Automatic polarity indication; Backlight; “OL” over range indication
Max height of use: 2000m
Pollution degree: 2
Insulation: double insulation
Power supply: 1 x 9V alkaline battery type NEDA1604, JIS006P, IEC6F22
Sizes: 190(L)x94(W)x48(H) mm
Weight (included batteries): 460g
Accessories:
K-Type Wire Probe TK101
Pair of Leads 4413-2
Adapter T10
Batteries and user manual
