Max.load (kN): 200kN
Load accuracy: ≤±1%
Load range: 2%-100%FS
Load resolution: 1/300000
Deformation Measurement Range: 2%～100%FS
Deformation accuracy: ≤±1%
Displacement resolution (mm): 0.01
Displacement error: ≤±0.5%
Max.piston stroke(mm): 250
Max piston moving speed: 0-90mm/min stepless speed adjusting
Crosshead lifting speed: 200mm/min
Max. tension test space: 780mm (can customize)
Max.Compression Test Space: 550mm (can customize)
Clamping method: Hydraulic clamp
Power supply: 3-phase,AC380V, 50Hz（can be customized）
