Max. Load (kN): 350KN
Structure: Full H Section Steel Frame
Test Accuracy Class: 1 Class
Test Force Measurement Range: 2%-100% FS
Test Force Relative Error Value: ≥±1%
Force Display Resolution: 1/20000
Deformation Effectively Measurement Range: 2%～100% FS
Deformation Display Resolution: 1/20000
Deformation Values Relative Error: ≥±0.5%
Displacement Resolution: 0.01 mm
Displacement Relative Error Value: ≥±0.5%
Effective Tensile Space: 0-4500 mm
Framework(Left and Right)Effective Spacing: 750 mm(Or According To Customers’Requirements)
Moving Beam Adjustment Speed: 0.05-500 mm/min
Clamping Way Of Tensile Fixtures: Bolt Method
Compression Fixture Configuration: Ф100 mm
Power Supply: 220V/50Hz/Three-phase Four-wire System
Overall Dimensions: （L*W*H) 4650mm*1260mm*670mm
