Test Force:
Kgf: 0.3、0.5、1、2、2.5、3、5、10
N: 2.94、4.9、9.8、19.6、24.5、29.4、49.0、98.0
Optical System: Observe and Measure Objectives：10x/40x
Test Range: 1HV-2967HV
Turret: Auto Rotating Turret
Loading Control: Auto loading dwell and unloading
Dwell Time: 5-60s adjustable
Illumination: LED / Halogen adjustable
Measuring System: iVicky 3.0 Auto Measuring Vickers System
PC System:
Operation System: Win10
Screen size: 10.6”
CPU: Intel I3
USB: Double USB (could insert USB and soft dog)
RAM: 2GB
Hard Disc: 32GB
Camera: 1.3MP Pixel, 1/2”CMOS Color Camera
Max Height of Specimen: 170mm
Instrument Throat: 130m
Power Supply: AC220V/50Hz; AC110V/60Hz
Dimension: 530x225x630mm
Packing Dimension: 630x460x710mm
Gross /Net Weight: 77Kg/56Kg
Execution Standard: ISO6507，ASTM E92，JIS Z2244，GB/T4340
Standard Delivery：
Vickers Intender
Φ100mm Working Stage
Hardness Block (700~800)HV10
USB Converting Cord
Hardness Block (400~500)HV1
10x Mechanical Eyepiece
10x Measuring Objective
40x Measuring Objective
Vickers Hardness Vision Measurement
Warranty Card / Qualified Certificate
Dust Cover
Toolbox
Power Cord
Pad Adapter
Operation Manual / Packing List
Optional Accessories：
X-Y Cross Anvil
Digital Micrometer Head
Unequal Specimen Clamp
LCD Display
Thin-Piece Clamp
Flat Precision Clamp
Filament Clamp
Heavy Anvil
V-shape Anvil
USB CMOS Camera
Camera Adapter
Vickers Measuring Software
