HORIBA HU-200TB-W Turbidity Meter (Kaolin: 1000 degrees, Formazin: 2000 degrees, Kaolin: 100 degrees)

Measurement range

Kaolin: 0 to 1000 (degrees) (Display range: 0 to 1100 (degrees)) or 0 to 1000 (mg/L)

Formazin: 0 to 2000 (Display range: 0 to 2200 )

PSL: 0 to 100 (degrees) (Display range: 0 to 110 (degrees))

Operating temperature range: −20℃ to 55℃(no freezing)

Operating humidity range: Relative humidity: 5% to 90% (no condensation)

Storage temperature: −25℃ to 65℃

Power supply

Rated power supply voltage: 100 V to 240 V AC ±10% 50/60 Hz

Power consumption: 35 VA (max.) when an automatic cleaner is connected.

Others: With built-in power switch for maintenance

Compatible standards

CE marking

EMC    :EN61326-1

Class A, Industrial electromagnetic environment

Safety :EN61010-1

RoHS :EN50581

9. Industrial monitoring and control instruments

FCC rules: Part 15 Class A

Structure

Installation: Outdoor installation type

Installation method: 50 A pole-mounted or wall-mounted

Protection class: IP65

Material of case: Aluminum alloy (coated with epoxy-modified melamine resin)

Material of mounting brackets: SUS304

Material of hood: SUS304 (coated with epoxy-modified melamine resin)

Material of display window: Polycarbonate

Display element: Reflective monochrome LCD
