Display: 95mm*20mm monochrome LCD display
Test Parameters: Withstand voltage/leakage current/insulation resistance
AC and DC Withstand Voltage Test
Voltage Resolution: 1V
Voltage Accuracy: 3%
Frequency: 50Hz/60Hz
AC Output: ——
AC Leakage current: 10mA
DC Output: 0.5kV~10KkV
DC Leakage current: 5mA
Current Resolution: 1μA
Current Accuracy: ±(3%+2 counts)
Voltage Rise Time: 0.1s~999.9s
Testing Time: 0.1s~999.9s
Arc Test Function: Level 1~9
Insulation Resistance Test
Insulation IR Range: 100KΩ~99GΩ
Insulation IR Accuracy: 5% (100KΩ-10GΩ)；20% (10GΩ-99GΩ)
Voltage Output: 0.1KV~2.0KV
Memory Group: 6 group
Interface: Handler，RS485, RS232(Optional)
Power Supply: Voltage: 198V-240V AC Frequency: 47Hz-63Hz, rated power; 100VA
Size: 374mm*280mm*99mm; Gross weight: 7.5kG
Accessories: 9950 HV line, 9900 sampling line, power cord
