Input voltage/Current:
15V/50A
150V/500A
Input power: 5000W
Min. operation voltage: 1.5V@500A
Min rise time@ FS current: 25us
CV mode
Range/Resolution:
15V/0.2mV
150V/2mV
Accuracy: ±(0.03%+0.02%FS)
CC mode
Range/Resolution:
50A/0.7mA
500A/7mA
Accuracy: ±(0.03%+0.02%FS)
CR mode
Range: 0.004Ω~3kΩ
Resolution: 16Bits
Accuracy: ±0.1%
CP mode
Range: 5000W
Resolution: 16Bits
Accuracy: ±(0.1%+0.1%FS)
Dynamic mode
Ta&Tb: 10us~50s
Min.resolution: 10us
Min. rise time: 3A/us
Read-back voltage
Range/Resolution:
15V/0.1mV
150V/1mV
Accuracy: ±(0.015%+0.01%FS)
Read-back current
Range/Resolution:
50A/0.3mV
500A/3mA
Accuracy: ±(0.03%+0.02%FS)
Read-back ripple
Range(U/I): 150V/500A
Bandwidth: 10Hz~250kHz
Accuracy: ±1%
Protection range
Over-power protection: 5250W
Over-current protection: 525A
Over-voltage protection: 158V
Over-temperature protection: ≒85℃
Specification
Dimension (L*W*D): 624mm*483mm*177.8mm
Gross Weight: 50Kg
