Output Rating:
Voltage: 0-30V
Current: 0-35A
Load Regulation:
Voltage: <0.01%+1mV
Current: <0.01%+0.1mA
Setting Value Resolution:
Voltage: 0.5mV
Current: 0.5mA
Readback Value Resolution:
Voltage: 0.1mV
Current: 0.1mA
Setting Value Accuracy:
Voltage: 0.01%+5mV
Current: 0.05%+2mA
Readback Value Accuracy:
Voltage: 0.03%+5mV
Current: 0.05%+25mA
Ripple:
Voltage: 5mvp-p
Current: 8mA rms
Volmeter Accuracy:
0-12V Accuracy: 0.02%+2mV
0-58V Accuracy: 0.02%+5mV
Milli ohmmeter accuracy:
10W. 0-1000mΩ Accuracy: 0.2%+3mΩ
1000-10000mΩ Accuracy: 0.2%+6mΩ
Working Condition: 0-40°C; 0-90%RH
Power Required: AC 120V/220V±10%; 50/60HZ
Weight: 45 Kg
Dimension: 428mm W × 184.5mm H × 531mm D
