Display: 4.3inch TFT-LCD display
Measurement items: ESR, DCV
Basic accuracy:
- Resistance: ±0.5%
- Voltage: ± 0.02%
Measurement range:
- Resistance: 0.0001mΩ~30.000Ω
- Voltage: 0.00001V~1000V
Signal source: AC 1kHz; open circuit voltage: <5V; Test current: <150mA
Range:
- Resistance: 3mΩ/30mΩ/300mΩ/3Ω/30Ω
- Auto and manual test mode in 5-level range
Sampling rate: 20 meas/sec,3 meas/sec
Temperature: Range:-10°C ~60°C; Accuracy:±1°C
Correction: Short-circuit reset for all ranges
Comparator: 200 set storage data
Internal data storage: Store up to 2400 set test data(upgradable to 4800 set)
Trigger: Internal/auto trigger
Interface: USB, EXPORT(port execution hold function)
Power supply: 12V/1700mAh lithium battery, AA (LR6) Alkaline Batteries x 8
Maximum rated power: 4VA
Dimensions: 208 mm (L) x120mm (W) x 52.5mm (D),without sleeve, weight:0.81kg
Included accessory: HT9363B, HT9371, HT9348, USB mini cable, charger, 0370 belt
