Operating voltage: AC220V, 50Hz, 10A
Glow wire temperature (current regulation): 0~1050℃
Heating current: (0~150A) continuously adjustable; and SCR automatic regulation
Temperature measurement accuracy: ±5°C (after 5 minutes of temperature stability)
Application time (TA): 0~99.99s can be set arbitrarily, set to 30s according to the standard, accuracy: 0.01S
Light off time (TI): With digital display time relay measurement, controlled by button, accuracy: 0.01S
Flame out time (TE): With digital display time relay measurement, controlled by button, accuracy: 0.01S
Glow wire presses the sample: 1±0.2N
Glow wire and sample relative displacement: 7mm
Maximum output power: 1000W
Dimensions: 1080×600×1400mm (Length × width × height)
Test room space: 0.5
