L x H x W: 483 mm x 295 mm x 284 mm (19.0 in x 11.6 in x 11.2 in)
Weight: 15.82 kg (34.88 lb)
Max. Width: 104 mm (4.09 in)
PRINT SPEED: 100–250 mm/s (4–10 ips)
PRINT RESOLUTION: 16 dots/mm
MEDIA:
Type: Labels and Tags, Linerless and Linered media
Max./Min. Width: 114/19 mm (4.5/0.75 in)
Thickness: 3 mil to 10.4 mil
Configuration: Roll-fed or fanfold
Sensing: Gap, notch, black mark, continuous
Label Roll Max. Diameter: 152 mm (6 in) for long door models; 213 mm (8.38 in) for all other models
Label Roll Core: 38–76 mm (1.5–3 in)
Type: Ribbons
Roll Max. Diameter: 80 mm (3.15 in), approx. 450 m (1,476 ft)
INTERFACES
Standard:
Ethernet 10/100 Mbps
RS-232, up to 115.2 KB/s
Supported Serial Protocols:
Fingerprint/Direct Protocol: XON/ XOFF, ENQ/ACK, DSR/DTR, RTS/CTS
IPL: XON/XOFF, Honeywell Std. Protocol
USB 2.0
USB Host (X1 on PM23c/PM43c,X2 on PM43)
MEMORY
Standard: 128 MB Flash memory, 128 MB
SDRAM, Multi-GB USB memory device (FAT16/FAT32)
USER INTERFACE: Color Touch UI, Icon UI
POWER SUPPLY
AC Voltage: 100 to 240V AC, 45 to 65 Hz
PFC Regulation: IEC320/C14
Power Consumption: Standby 9W; Peak 300W
OPERATING ENVIRONMENT
Ambient Operating Temperature: +5°C to +40°C (+41°F to +104°F)
Storage Temperature: -20°C to +70°C (-4°F to +152°F)
Humidity: 20 to 80% non-condensing
